HP elitedisplay e230t User Manual

Rear components
Component Function
1 Master power switch Turns o all power to the monitor.
NOTE: Putting the switch in the O position will yield the
lowest power state for the monitor when not in use.
2 Power connector Connects the AC power cord to the monitor.
3 DisplayPort connector Connects the DisplayPort cable to the monitor.
4 HDMI connector Connects the HDMI cable to the monitor.
5 VGA connector Connects the VGA cable to the monitor.
6 USB 3.0 upstream connector Connects the USB hub cable from the source device to the
monitor.
7 USB connectors Connect USB devices to the monitor.
Product features and components 3

HP elitedisplay e230t Specifications

General

Color gamut	72 %
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Backlight type	W-LED
Glossy display	No
Display diagonal	23 \
Touch technology	Multi-touch
Touchscreen type	Table
Display brightness	250 cd/m²
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.42 cm
Number of simultaneous touchpoints	10
Product color	Black, Silver
Country of origin	China
Placement supported	Horizontal
Display viewable area (HxV)	509.184 x 286.416 mm
Dimensions (W x D x H) with stand	520.8 x 189 x 486.6 mm
Cables included	AC, USB, VGA
Tilt angle range	-5 - 25 °
Height adjustment	150 mm
Power supply type	AC
Power consumption (max)	57 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	189 mm
Width (with stand)	520.8 mm
Height (with stand)	486.6 mm
Weight (with stand)	4900 g
Depth (without stand)	52.3 mm
Height (without stand)	311.95 mm
