HP elitedisplay e230t User Manual

Using the on-screen display (OSD) menu
Use the on-screen display (OSD) menu to adjust the monitor screen image based on your preferences. You can
access and make adjustments in the OSD menu using the buttons on the monitor's front bezel.
To access the OSD menu and make adjustments, do the following:
1. If the monitor is not already on, press the Power button to turn on the monitor.
2. To access the OSD menu, press one of the four front bezel buttons to activate the buttons, and then
press the Menu button to open the OSD.
3. Use the three Function buttons to navigate, select, and adjust the menu choices. The button labels are
variable depending on the menu or submenu that is active.
The following table lists the menu selections in the OSD menu.
Main Menu Description
Brightness Adjusts the brightness level of the screen.
Contrast Adjusts the screen contrast.
Color Control Selects and adjusts the screen color.
Input Control Selects the video input signal.
Image Control Adjusts the screen image.
Power Control Adjusts the power settings.
Menu Control Adjusts the on-screen display (OSD) and Function button controls.
Management Enables/disables DDC/CI support and returns all OSD menu settings to the factory default settings.
Language Selects the language in which the OSD menu is displayed. The factory default is English.
Information Displays important information about the monitor.
Exit Exits the OSD menu screen.
Using the on-screen display (OSD) menu 17

HP elitedisplay e230t Specifications

General

Color gamut	72 %
Pixel pitch	0.2652 x 0.2652 mm
Aspect ratio	16:9
Screen shape	Flat
LED backlight	Yes
Backlight type	W-LED
Glossy display	No
Display diagonal	23 \
Touch technology	Multi-touch
Touchscreen type	Table
Display brightness	250 cd/m²
Display technology	LED
Touchscreen technology	Capacitive
Contrast ratio (dynamic)	500000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	58.42 cm
Number of simultaneous touchpoints	10
Product color	Black, Silver
Country of origin	China
Placement supported	Horizontal
Display viewable area (HxV)	509.184 x 286.416 mm
Dimensions (W x D x H) with stand	520.8 x 189 x 486.6 mm
Cables included	AC, USB, VGA
Tilt angle range	-5 - 25 °
Height adjustment	150 mm
Power supply type	AC
Power consumption (max)	57 W
Power consumption (standby)	0.5 W
Power consumption (typical)	29 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	2
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	189 mm
Width (with stand)	520.8 mm
Height (with stand)	486.6 mm
Weight (with stand)	4900 g
Depth (without stand)	52.3 mm
Height (without stand)	311.95 mm
