Item Component Spare part number
(1) Display assembly (includes webcam/microphone module and wireless antenna cables):
15.6-in, AntiGlare, FHD, LED, TouchScreen display assembly for use on all computer models 788475-001
15.6-in, AntiGlare, HD, LED, TouchScreen display assembly for use on all computer models 788474-001
15.6-in, BrightView, FHD, LED, non-TouchScreen display assembly for use only on
computer models equipped with an Intel processor
720552-001
15.6-in, BrightView, HD, LED, non-TouchScreen display assembly for use only on
computer models equipped with an Intel processor
720551-001
The subcomponents for the non-TouchScreen display assembly are also available as spare part kits. For more display
assembly spare part information, see
Display assembly subcomponents on page 21).
(2) Top cover:
Includes red Beats logo 760040-001
Includes grey Beats logo 774153-001
(3) Power button board (includes cable) 720553-001
(4) Keyboard (includes keyboard cable and backlight cable):
For use in Canada 760743-DB1
For use in Latin America 760743-161
For use in Japan 760743-291
For use in South Korea 760743-AD1
For use in Taiwan 760743-AB1
For use in Thailand 760743-281
For use in the United States 760743-001
(5) Keyboard shield 734817-001
(6a) TouchPad assembly (includes TouchPad bracket (6b), TouchPad button board, TouchPad,
and cables)
760041-001
Tape kit, includes tape, gasket, Mylar insulator, top case insulator, and gasket boss (not
illustrated)
807975-001
(7) Speakers (include left and right speakers, 2 cables, and 4 isolators) 720561-001
(8) Power connector cable
For use in models with UMA graphics 720537-001
For use in models with discrete graphics 720538-001
(9) Connector board (includes audio jack, RJ-45 jack, USB port, and 2 cables)
For use only on models equipped with a graphics subsystem with discrete memory 765146-001
For use only on models equipped with a graphics subsystem with UMA memory 765145-001
(10) System board (includes replacement thermal material):
For use only on computer models equipped with an Intel Core i7-4702HQ processor, a
graphics subsystem with discrete memory, and the Windows 8 Professional operating
system
765736-601
Computer major components 17
