HP ENVY m6 User Manual

Item Component Spare part number
For use only on computer models equipped with an Intel Core i7-4702HQ processor, a
graphics subsystem with discrete memory, and the Windows 8 Professional Standard
system
765736-501
For use only on computer models equipped with an Intel Core i7-4702HQ processor, a
graphics subsystem with discrete memory, and a non-Windows 8 operating system
765736-001
For use only on computer models equipped with an Intel Core i7-4722HQ processor, a
graphics subsystem with discrete memory, and the Windows 8 Professional operating
system
801521-601
For use only on computer models equipped with an Intel Core i7-4722HQ processor, a
graphics subsystem with discrete memory, and the Windows 8 Professional Standard
system
801521-501
For use only on computer models equipped with an Intel Core i7-4722HQ processor, a
graphics subsystem with discrete memory, and a non-Windows 8 operating system
801521-001
For use only on computer models equipped with a separate processor, a graphics
subsystem with UMA memory, and the Windows 8 Professional operating system
760289-601
For use only on computer models equipped with a separate processor, a graphics
subsystem with UMA memory, and the Windows 8 Standard operating system
760289-501
For use only on computer models equipped with a separate processor, a graphics
subsystem with UMA memory, and a non-Windows 8 operating system
760289-001
(11) Processor (includes replacement thermal material):
NOTE: Separate processors can only be used in system board with spare part numbers 760289-001, 760289-501, and
760289-601.
Intel Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz FSB, 3.0-MB
L3 cache, dual core, 37 W)
768420-001
Intel Core i5-4200M 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB, 3.0-MB
L3 cache, dual core, 37 W)
737328-001
(12) Heat sink (includes replacement thermal material):
For use only on computer models equipped with an Intel processor and a graphics
subsystem with discrete memory
765737-001
For use only on computer models equipped with an Intel processor and a graphics
subsystem with UMA memory
720541-001
(13) Fan (includes cable) 720235-001
(14) Subwoofer (includes cable and 3 isolators) 720563-001
(15) Base enclosure (includes 4 rubber feet, battery lock latch, battery release latch, and RJ-45 cover):
Includes red Beats logo 760035-001
Includes grey Beats logo 774152-001
Rubber Kit (not illustrated, includes front and rear rubber feet, base enclosure screw cover,
and display bezel rubber screw covers)
720559-001
(16) RTC battery: 718440-001
(17) WLAN module:
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC Combo Adapter 753076-001
Intel Dual Band Wireless-AC 3160 802.11ac 1×1 WiFi + BT 4.0 Combo Adapter 710662-001
18 Chapter 3 Illustrated parts catalog

HP ENVY m6 Specifications

General

LED backlight	Yes
Display surface	Gloss
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Number of SSDs installed	0
On-board graphics card ID	0x166
Discrete graphics card model	AMD Radeon HD 7670M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	Beats Audio
Number of built-in speakers	2
Video capturing speed	30 fps
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit LAN, WLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Operating system installed	Windows 8
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor ARK ID	71458
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	250.7 mm
Width	379.5 mm
Height	26.5 mm
Weight	2400 g
