HP FlexNetwork 5140 EI Series User Manual

40
Item
HPE 5140 24G PoE+ 2SFP+
2XGT EI
HPE 5140 48G PoE+ 2SFP+ 2XGT
EI
Chassis leakage
current compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
Melting current of
power supply fuse
2 A/250 V
Cooling system
Using fixed fan trays to draw ambient air in from the chassis left side and exhaust
heated air from the chassis right side.
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating humidity 5% to 95%, noncondensing
Fire resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
Table 15 Technical specifications for PoE switch models (2)
Item
HPE 5140 48G PoE+ 4SFP+ EI
HPE 5140 24G PoE+ 4SFP+ EI
Dimensions (H × W ×
D)
43.6 × 440 × 400 mm (1.72 × 17.32 ×
15.75 in)
43.6 × 440 × 260 mm (1.72 × 17.32
×10.24 in)
Weight ≤ 6 kg (13.23 lb) ≤ 4.5 kg (9.92 lb)
Console port
• 1 × serial console port
• 1 × micro USB console port
• When both ports are connected, only the micro USB console port is available.
10/100/1000BASE-T
autosensing Ethernet
port
48
24 (The four highest-numbered
10/100/1000BASE-T autosensing
Ethernet ports form combo interfaces
with their corresponding SFP ports,
respectively.)
SFP port N/A
4 (Each and its corresponding
10/100/1000BASE-T autosensing
Ethernet port form a combo interface.)
SFP+ port 4 4
Input voltage
AC power source:
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
DC power source: RPS1600-A
• Rated voltage: –54 VDC to –57 VDC
• Max voltage:
 Single DC input: –44 VDC to –60 VDC
• AC and DC inputs: –54 VDC to –57 VDC
Maximum PoE power
per port
30 W 30 W
Total PoE power
• AC: 370 W
• DC: 740 W
AC: 370 W
DC: 740 W
Minimum power
consumption
• AC: 37 W
• DC: 29 W
AC: 24 W
DC: 17 W
Maximum power
consumption
(including PoE power
• AC: 478 W
• DC: 825 W
AC: 451 W
DC: 793 W
