Figure 49 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
HPE 5140 48G PoE+ 4SFP+ EI
Figure 50 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Port LED mode switching button
(5) System status LED (SYS)
(6) RPS status LED (RPS)
(7) Mode LED (MODE)
(8) Micro USB console port
(9) SFP+ port
(10) SFP+ port LED
Figure 51 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) DC-input power receptacle
1
2
3
1 3 4
6
2 5
7810 9
1
2 3
