HP FlexNetwork 5140 EI Series User Manual

39
Item
HPE 5140 24G SFP w/8G Combo 4SFP+ EI
• 2 × PSR150-A1: 23 W
• 2 × PSR150-D1: 22 W
Maximum power
consumption
• 1 × PSR150-A1: 48 W
• 1 × PSR150-D1: 51 W
• 2 × PSR150-A1: 55 W
• 2 × PSR150-D1: 57 W
Chassis leakage current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
Melting current of power
supply fuse
• PSR150-A1: 6.3 A/250 V
• PSR150-D1: 8 A/250 V
Cooling system
Using fixed fan trays to draw ambient air in from the left side and port side and
exhaust heated air from the right side.
Operating temperature –5°C to +45°C (23°F to 113°F)
Operating humidity 5% to 95%, noncondensing
Fire resistance
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC
60950-1/GB4943.1
PoE switch models
Table 14 Technical specifications for PoE switch models (1)
Item
HPE 5140 24G PoE+ 2SFP+
2XGT EI
HPE 5140 48G PoE+ 2SFP+ 2XGT
EI
Dimensions (H × W ×
D)
43.6 × 440 × 320 mm (1.72 × 17.32 ×
12.60 in)
43.6 × 440 × 320 mm (1.72 × 17.32 ×
12.60 in)
Weight ≤ 4.5 kg (9.92 lb) ≤ 4.5 kg (9.92 lb)
Console port 1 × serial console port
10/100/1000BASE-T
autosensing Ethernet
port
24 48
10/5/2.5/1GBASE-T
autosensing Ethernet
port
2
SFP+ port 2
Input voltage
• Rated voltage: 100 VAC to 240 VAC @ 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47 to 63 Hz
Maximum PoE power
per port
30 W
Total PoE power 370 W
Minimum power
consumption
20 W 32 W
Maximum power
consumption
(including PoE power
consumption)
450 W 470 W
