5
Installation tools
No installation tools are provided with the switch. Prepare the following tools yourself as required.
Flat-blade screwdriver
Phillips screwdriver
ESD wrist strap
Needle-nose pliers
Diagonal pliers
Crimping tool
Marker
Heat gun
Installation accessories
All the installation accessories except the following installation accessories are provided with the
switch:
M6 screws and floating nuts.
PSR150-A1 (JD362B) AC power supply.
PSR150-D1 (JD366B) DC power supply.
Table 4 Installation accessories
5380-0493
1 U two-hole mounting bracket kit
(including one pair of mounting brackets
and four M4 countersunk screws)
1 kit
HPE 5140 24G 4SFP+ EI
HPE 5140 48G 4SFP+ EI
HPE 5140 24G PoE+ 4SFP+ EI
HPE 5140 48G PoE+ 4SFP+ EI
R8M91A
HPE 5140 Rack Mount Kit (including
one pair of mounting brackets and four
M4 countersunk screws)
1 kit
HPE 5140 8G 2SFP 2GT
Combo EI
5066-0850
1 U four-hole mounting bracket kit
(including one pair of mounting brackets
and eight M4 countersunk screws)
1 kit
HPE 5140 24G SFP w/8G
Combo 4SFP+ EI
HPE 5140 24G PoE+ 2SFP+
2XGT EI
HPE 5140 48G PoE+ 2SFP+
2XGT EI
HPE 5140 24G 2SFP+ 2XGT
EI
N/A
M6 screw and floating nut (user
supplied)
As required All HPE 5140 EI switches
