49
Removable components
WARNING!
Y
ou can replace one of the two power supplies operating in 1+1 redundancy on the
HPE 5140 24G
SFP w/8G
Combo 4SFP+ EI switches. To avoid device damage and bodily injury, make sure the
power supply is powered off before removing it.
The HPE 5140 24G SFP w/8G Combo 4SFP+ EI switches provide two power supply slots. One
power supply can meet the power requirement of the switch. You can install two power supplies on
the switch for 1+1 redundancy. Table 16 describes the power supplies available for the switch.
Table 16 Power supplies available for the HPE 5140 24G SFP w/8G Combo 4SFP+ EI switch
Power supply
model
Item Specification Remarks
PSR150-A1
Rated input voltage
100 VAC to 240 VAC @ 50
Hz or 60 Hz
HPE PSR150-A & PSR150-D
Power Supplies User Guide
Max input voltage
90 VAC to 264 VAC @ 47
Hz to 63 Hz
Max output power 150 W
PSR150-D1
Rated input voltage –48 VDC to –60 VDC
Max input voltage –36 VDC to –72 VDC
Max output power 150 W
Ports and LEDs
Ports
Console port
The following switch models each provide a serial console port and a micro USB console port on the
front panel. The other HPE 5140 EI switch models each provide only a serial console port.
•
HPE 5140 24G 4SFP+ EI
•
HPE 5140 48G 4SFP+ EI
•
HPE 5140 24G PoE+ 4SFP+ EI
•
HPE 5140 48G PoE+ 4SFP+ EI
•
HPE 5140 24G SFP w/8G Combo 4SFP+ EI
Table 17 Console port specifications
Item
Serial console port
Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
