Illustrated parts catalog 3–3
Item Description Spare Part Number
(1) Display assembly (includes 2 WLAN antenna transceivers and cables, webcam, microphones, and logo)
16.0-inch, WXGA, AntiGlare, FHD, dual lamp with webcam and microphone 497936-001
16.0-inch, WXGA, AntiGlare, HD, dual lamp with webcam and microphone 496468-001
16.0-inch, WXGA, AntiGlare, HD, single lamp with webcam and microphone 497937-001
✎
See “Display assembly components” on page 3-8 for information on display assembly spare part numbers.
(2) Switch cover 496471-001
(3) Keyboard cover (includes LED board and cable) 496472-001
(4) Keyboard (includes cable)
For use in Denmark, Finland, and Norway 508199-DH1
For use in France 496672-051
For use in French Canada 508199-121
For use in Germany 496672-041
For use in Greece 496672-DJ1
For use in Italy 496672-061
For use in Japan 508199-291
For use in Latin America 496672-161
For use in the Netherlands 496672-B31
For use in Russia 496672-251
For use in Saudi Arabia 508199-171
For use in South Korea 508199-AD1
For use in Spain 496672-071
For use in Switzerland 496672-BG1
For use in Taiwan 496672-AB1
For use in Thailand 508199-281
For use in Turkey 496672-141
For use in the United Kingdom 496672-031
For use in the United States 496672-001
(5) Power button board (includes cable) 496482-001
Plastics Kit, includes: 496477-001
(6a) ExpressCard slot bezel
(6b) Hard drive cover
(6c) WLAN module compartment cover
✎
See “Plastics Kit” on page 3-7 for more Plastics Kit spare part information.
(7) Bluetooth module
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable.
The Bluetooth module cable is available using spare part number 496461-001.
483113-001
(8) Bluetooth module cable 496461-001
(Continued)
