Illustrated parts catalog 3–4
(9a) Base enclosure, includes: 496469-001
(9b) Subwoofer
(9c) Power connector cable
Power connector cable bracket (not illustrated)
Fan (see also item 16)
5 rubber feet (not illustrated)
Rubber Feet Kit (not illustrated, includes 5 rubber feet) 496478-001
(10) Top cover (includes fingerprint reader board, fingerprint reader board cable, TouchPad,
and TouchPad cables)
496470-001
(11) TouchPad on/off button board (incudes cable) 496473-001
(12) Speaker assembly 496476-001
(13) System board (includes 512 MB of graphics subsystem memory and replacement
thermal material)
496460-001
(14) Processor (includes replacement thermal material):
Intel Core2 Duo T9800 2.93-GHz processor with 6-MB L2 cache and 1066-MHz FSB 507951-001
Intel Core2 Duo T9600 2.80-GHz processor with 6-MB L2 cache and 1066-MHz FSB 500604-001
Intel Core2 Duo T9550 2.66-GHz processor with 6-MB L2 cache and 1066-MHz FSB 507953-001
Intel Core2 Duo T9500 2.53-GHz processor with 6-MB L2 cache and 1066-MHz FSB 500603-001
Intel Core2 Duo T8700 2.53-GHz processor with 3-MB L2 cache and 1066-MHz FSB 507960-001
Intel Core2 Duo T8600 2.40-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500601-001
Intel Core2 Duo T8400 2.26-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500600-001
Intel Core2 Duo T6600 2.20-GHz processor with 3-MB L2 cache and 1066-MHz FSB 513593-001
Intel Core2 Duo T7550 2.13-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500605-001
Intel Core2 Duo T6400 2.06-GHz processor with 3-MB L2 cache and 1066-MHz FSB 513592-001
Intel Core2 Duo T7350 2.00-GHz processor with 3-MB L2 cache and 1066-MHz FSB 503391-001
(15) Fan/heat sink assembly (includes replacement thermal material) 496488-001
(16) Fan 514290-001
(17) Audio/infrared board (includes cable) 496483-001
(18) USB board (includes cable) 496489-001
Cable Kit, includes: 496481-001
(19) TV tuner module cable
(20) Battery
12-cell, 8.80-Ah Li-ion battery 497695-001
6-cell, 2.55-Ah Li-ion battery 497694-001
(Continued)
Item Description Spare Part Number
