HPE StoreOnce 5100 System Components
The HPE StoreOnce 5100 System is based on an HPE ProLiant DL380 Gen9 server.
The following table lists Spares Part Numbers for the main components in the head server. See
the HPE StoreOnce 5100 System Capacity Upgrade Kit components (page 13) for information
about components in the storage enclosure.
NOTE: This is an offline list, created from partsurfer. If there is a problem with these Spares
Part Numbers, check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem
exists in the online source, use the feedback form to log the problem: http://partsurfer.hpe.com/
ContactUs.aspx.
Table 4 HPE StoreOnce 5100 System, BB915A
Hot plugDescriptionSpares Part NumberPart
YesSPS-DRV HD 900GB 6G
SAS 10K 2.5 DP EN SC
653971-001OS Hard disk drive (900GB)
YesSPS-DRV HD 4TB 3.5
7.2K 6G SAS SC MDL
695842-001Hard disk drive (4 TB)
NoSPS-BD AROC P440ar
Cntrlr
749796-001SmartArray RAID Controller
NoSPS-BATT PACK
ENHANCED MegaCell
96W
815983-001SmartArray Battery Pack
YesSPS-PS 800W FS
PlatinumPlus
754381-001Power supply
NoSPS-BD Smart Array PCIe
SAS Expander
761879-001SAS expander
NoCable, HD Mini SAS to
Mini SAS, 16 inch
694008–002Cable, HD Mini SAS to Mini
SAS, 16 inch 3500/5100
3500/5100 Defender to
shiner
between the SAS expander
and the p1224
NoSPS-CBL Mini SAS 12LFF
+ 15LFF Kit
784627-001Internal SAS Ribbon Cable
from SAS expander to the
backplane
NoSPS-PCA 4e/4i w/o
Encryption
842475-001RAID controller p1224
NoSPS-BD DDR3 MINI
DIMM MOD 1Gx72
633542-001Mini DIMM module (cache
module for p1224)
NoSPS-CA CAPACITOR 36in
FL
660093-001SuperCapacitor (for p1224)
NoSPS-PCA dl380 2-SFF
rear Backplane
777280-001SAS/SATA backplane
board - Mounts on the rear
of the 2-bay small form
factor (SFF) hard drive cage
NoSPS-CA SAS
2SFF+*SFF+
784629-001Mini-SAS cable kit (Includes
six cables) - For connecting
AROC/H240+P440 Kit
between the 8-bay and
2-bay small form factor
(SFF) hard drive cages and
the H240 host bus adapter
or the P440ar controller
board
HPE StoreOnce 5100 System Components 11
