Set 1 Running
NOTE: The addition of storage will take a minimum of two hours to complete. You will not
be able to complete the next steps until storage is formatted.
6. Using an SFTP client copy the saved configuration zip file to the config folder on the
appliance.
• Using Linux
sftp Admin@<IP_address>
cd config
put <config_filename>.zip
exit sftp
• Using a Windows sftp client
Ensure the File Protocol is set to SFTP, not SCP.
Login as Admin.
Copy <config_filename>.zip to config.
7. Use the following StoreOnce CLI command to check that the file has been uploaded:
config show list
8. Run the StoreOnce CLI command:
config restore devices <config_filename>
This will restore device settings for the appliance.
9. After configuration recovery backups can be configured and replication mappings
re-established in order to reverse replicate date back to the appliance (see replication
information in the user guide)
Performing a configuration restore 71

HP HPE StoreOnce 5100 Series Specifications

General

Model	HPE StoreOnce 5100 Series
Processor	Intel Xeon
Power Supply	Redundant power supplies
Management	HPE StoreOnce Management Console
Replication	Yes
Memory	Up to 96 GB
Network Interfaces	10GbE, 1GbE
Supported Protocols	CIFS, NFS, VTL, OST

Summary

Finding Part Numbers for Replacement Parts

General Precautions and Safety Guidelines

Component Replacement Guidelines

Provides guidelines for safely removing and installing components.

Safety Precautions

General safety instructions to prevent injury and equipment damage.

Preventing Electrostatic Discharge

Steps to prevent damage from static electricity during handling.

Equipment Symbols

Explains symbols indicating potentially hazardous conditions.

Identifying Problems

POST Messages and Troubleshooting

Information on POST messages and hardware-related troubleshooting.

Using the StoreOnce GUI to Identify a Problem

How to use the GUI for troubleshooting, including viewing logs and hardware status.

Using the StoreOnce CLI to Identify a Problem

How to use CLI commands for hardware troubleshooting and status checks.

Using LEDs to Diagnose Problems

Server Front Panel LEDs

Details front panel LEDs for 3100, 3500, and 5100 systems.

Disk Drive LEDs

Explains disk drive LEDs, including status and activity indicators.

System Board and Rear Panel LEDs

Storage Enclosure and System Status LEDs

Disk Drive Status LEDs

Power On/Off, Firmware Upgrades and Other Processes

Power On/Off Requirements

Upgrading BIOS or Hardware Firmware Components

Steps for updating BIOS and hardware firmware.

Performing Firmware Maintenance from the StoreOnce GUI

Performing Firmware Maintenance from the StoreOnce CLI

Upgrading StoreOnce Software

Running a System Self Test

How to run the system confidence check for diagnostics.

HPresetpassword Account

Replacing the System's Motherboard

After Replacing the Motherboard—BIOS and iLO Configuration

Steps for configuring BIOS and iLO after motherboard replacement.

RBSU Settings for HPE StoreOnce 3100 System

RBSU Settings for HPE StoreOnce 3500 Series and HPE StoreOnce 5100 System

Replacing the p1224 RAID Controller and Components

Identifying a RAID Controller Failure

How to identify RAID controller failures through logs and GUI.

p1224 RAID Controller

The RAID Cache Module and SuperCapacitor

Replacement Procedure

General procedure for replacing RAID components.

Disk Replacement

Ordering the Correct Replacement Disk for a Failed Disk

How to identify and order the correct replacement disk.

Replacing a Hot-Plug Hard Disk

Step-by-step guide to replacing a hot-plug hard disk.

If Multiple Disks Fail and a RAIDset is Broken

Procedure for rebuilding storage after multiple disk failures.

The QR ISO Image

Download Quick Restore ISO Image

Instructions to download the Quick Restore ISO image.

Create a Bootable QR USB Stick

Steps to create a bootable USB drive with the QR ISO.

Delete Storage

Boot the Appliance and Install the StoreOnce Software

Steps to boot and install software using the QR ISO.

Performing a Configuration Restore

How to restore appliance configuration from a file.
