MPS-2224-AI
ITT upgrade Baldor parameters
Changed parameters are marked by a Î
Level 1 Blocks–S/W Ver. 3.12
Block Title Parameter P# Factory
Setting
HP Indigo
Setting
ÎPRESET
PRESET SPEEDS #1 1001 0 RPM 1863 RPM
(1859)
PRESET SPEEDS #2 1002 0 RPM 155 RPM
PRESET SPEEDS #3 1003 0 RPM 0 RPM
PRESET SPEEDS #4 1004 0 RPM 0 RPM
PRESET SPEEDS #5 1005 0 RPM 0 RPM
PRESET SPEEDS #6 1006 0 RPM 0 RPM
PRESET SPEEDS #7 1007 0 RPM 0 RPM
PRESET SPEEDS #8 1008 0 RPM 0 RPM
PRESET SPEEDS #9 1009 0 RPM 0 RPM
PRESET SPEEDS #10 1010 0 RPM 0 RPM
PRESET SPEEDS #11 1011 0 RPM 0 RPM
PRESET SPEEDS #12 1012 0 RPM 0 RPM
PRESET SPEEDS #13 1013 0 RPM 0 RPM
PRESET SPEEDS #14 1014 0 RPM 0 RPM
PRESET SPEEDS #15 1015 0 RPM 0 RPM
ACCEL/DECEL ACCEL TIME #1 1101 3.0 SEC 1.3 SEC
DECEL TIME #1 1102 3.0 SEC 3.7 SEC
S-CURVE #1 1103 0 % 0 %
ACCEL TIME #2 1104 3.0 SEC 3.0 SEC
DECEL TIME #2 1105 3.0 SEC 3.0 SEC
S-CURVE #2 1106 0 % 0 %
JOG
SETTINGS
JOG SPEED 1201 200 RPM 155 RPM
JOG ACCEL TIME 1202 3.0 SEC 3.0 SEC
JOG DECEL TIME 1203 3.0 SEC 0 SEC
JOG S- CURVE TIME 1204 0 % 0 %
KEYPAD
SETUP
KEYPAD STOP KEY 1301 REMOTE ON REMOTE ON
KEYPAD STOP MODE 1302 REGEN REGEN
KEYPAD RUN FWD 1303 ON ON
Proprietary and Confidential MPS-2224-AI Rev 00 Page 41 of 55
