MPS-2224-AI
Level 1 Blocks–S/W Ver. 3.12
Block Title Parameter P# Factory
Setting
HP Indigo
Setting
KEYPAD RUN REV 1304 ON OFF
KEYPAD JOG FWD 1305 ON ON
KEYPAD JOG REV 1306 ON OFF
LOC. HOT START 1307 OFF OFF
ÎINPUT
OPERATING MODE 1401 KEYPAD SERIAL
(15SPD)
Î
COMMAND SELECT 1402 +/-10 VOLTS SERIAL
(+/-10V)
ANA CMD INVERSE 1403 OFF OFF
ANA CMD OFFSET 1404 0.0 % 0.0 %
ANA 2 DEADBAND 1405 0.00 V 0.00V
ANA 1 CUR LIMIT 1406 OFF OFF
OUTPUT OPTO OUTPUT #1 1501 READY READY
OPTO OUTPUT #2 1502
ZERO
SPEED
ZERO
SPEED
OPTO OUTPUT #3 1503 AT SPEED AT SPEED
OPTO OUTPUT #4 1504 FAULT FAULT
ZERO SPD SET PT 1505 200 RPM 1 RPM
AT SPEED BAND 1506 100 RPM 1000 RPM
SET SPEED 1507
Rated Motor
Speed
1 RPM
ANALOG OUT #1 1508 ABS SPEED ABS SPEED
ANALOG OUT #2 1509
MOTOR
CURRENT
MOTOR
CURRENT
ANALOG #1 SCALE 1510 100 % 100 %
ANALOG #2 SCALE 1511 100 % 100 %
POSITION BAND 1512 CALC 3
ÎVECTOR
CONTROL
CTRL BASE SPEED 1601 CALC 1480 RPM
(1500 RPM)
FEEDBACK FILTER 1602 CALC 5
FEEDBACK ALIGN 1603 FORWARD FORWARD
Î
CURRENT PROP
GAIN
1604 20 10
(35)
Î
CURRENT INT GAIN 1605 50 13
(16)
