MPS-2224-AI
Level 1 Blocks–S/W Ver. 3.12
Block Title Parameter P# Factory
Setting
HP Indigo
Setting
SPEED PROP GAIN 1606 10 20
Î
SPEED INT GAIN 1607 1.00 HZ 3
(0.9)
Î
SPEED DIFF GAIN 1608 0 3
(5)
Î
POSITION GAIN 1609 CALC 25
(0)
SLIP FREQUENCY 1610 CALC 3.33 HZ
STATOR R1 1611 CALC 1.7
STATOR X1 1612 CALC 3
LEVEL 2
BLOCK
ENTERS LEVEL 2 MENU
PRESS ENTER FOR PROGRAMMING
EXIT
Exit programming mode and return to
display mode
Level 2 Blocks– S/W Ver. 3.12
Block Title Parameter Parameter # Factory
Setting
HP Indigo
Setting
OUTPUT LIMITS
OPERATING
ZONE
2001
STD CONST
TQ
STD VAR TQ
MIN OUTPUT
SPEED
2002 0 RPM 0 RPM
MAX OUPUT
SPEED
2003
Rated Motor
Speed
2000 RPM
PK CURRENT
LIMIT
2004
PK Control
Rating
4.2 A
PWM
FREQUENCY
2005 2.5 KHz 2.9 KHZ
CUR RATE LIMIT 2006 0.000 SEC 0.000 SEC
CUSTOM UNITS
DECIMAL
PLACES
2101 5 5
VALUE AT SPEED 2102
00000/010000
RPM
0./1000 RPM
UNITS OF
MEASURE
2103 **** ****
PROTECTION OVERLOAD 2201 FOLDBACK FOLDBACK
