HP Indigo S2000 - Page 7

MPS-2224-AI
Level 2 Blocks– S/W Ver. 3.12
Block Title Parameter Parameter # Factory
Setting
HP Indigo
Setting
EXTERNAL TRIP 2202 OFF OFF
LOCAL ENABLE
IMP
2203 OFF OFF
FOLLOWING
ERROR
2204 OFF ON
TORQUE
PROVING
2205 OFF OFF
MISCELLANEOUS
RESTART
AUTO/MAN
2301 MANUAL AUTOMATIC
RESTART
FAULT/HR
2302 0 0
RESTART DELAY 2303 0 SEC 0 SEC
FACTORY
SETTINGS
2304 NO NO
Î
HOMING SPEED 2305 100 RPM 970 RPM
(0 RPM)
Î
HOMING OFFSET 2306 Encoder
Counts
12750
(0)
SECURITY SECURITY STATE 2401 OFF OFF
CONTROL
ACCESS
TIMEOUT
2402 0 SEC 0 SEC
ACCESS CODE 2403 9999 9999
MOTOR DATA
MOTOR
VOLTAGE
2501 Factory Set 230 V
MOTOR RATED
AMPS
2502 Factory Set 1.9 A
MOTOR RATED
SPD
2503 1750 RPM 1400 RPM
MOTOR RATED
FREQ
2504 60.0 HZ 50 HZ
MOTOR MAG
AMPS
2505 CALC 0.8 A
Î
ENCODER
COUNTS
2506 1024 PPR 157 PPR
(472)
RESOLVER
SPEEDS
2507 0 SPEED 0 SPEED
CALC PRESETS 2508 NO NO
Proprietary and Confidential MPS-2224-AI Rev 00 Page 44 of 55
