HP Integrity BL860c i4 - Preparing the Server Blade for Servicing

3 BL8x0c i4 Base Unit (part number
AM377-2001A)
AM377-6901A
7 SAS disk backplane (part number
AD399-60009)
AD399-67009
10 System battery —
11 Smart Array battery —
2 Front bezel —
Description with Part Number Spare Part Number
1 SAS Hard Drive Blank —
2 System Chassis (part number AD399-2102F) AD399-2102F
3 CPU Heatsink (part number AD399-2120D) 612269-001
4 CPU Socket Dust Cover (& airflow baffle) (part
number AD399-2134A)
AD399-2134A
5 Blade Top Cover (part number AD399-2101B) AD399-2101B
6 Memory Airflow Baffle (part number
AD399-2128B)
AD399-2128B
Preparing the server blade for servicing
To service an internal server blade component, power off the server blade and remove it from the server
blade enclosure.
112 Preparing the server blade for servicing
