HP M24FD User Manual

3
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
● 60.5 (23.8 in) diagonal viewable screen area with 1920 × 1080 FHD plus full-screen support for lower
resolutions; includes custom scaling for maximum image size while preserving original aspect ratio
● 68.6 cm (27.0 in) diagonal viewable screen area with 1920 × 1080 FHD resolution, plus full-screen
support for lower resolutions; includes custom scaling for maximum image size while preserving
original aspect ratio
● Liquid crystal display (LCD) with active matrix and in-plane switching (IPS)
● Wide color gamut to provide coverage of sRGB color spaces
● Nonglare panel with an LED backlight
● Wide viewing angle to allow viewing from a sitting or standing position, or moving from side to side
● Tilt adjustment capability
● High–Definition Multimedia Interface (HDMI), USB and USB Type-C port, and VGA video inputs
● Four on-screen display (OSD) buttons, three that you can reconfigure to quickly allow selection of the
most commonly used operations
● Plug and Play capability if supported by your operating system
● Security cable slot on the rear of the monitor for an optional security cable
● On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
● HP Display Assistant software for adjusting monitor settings and enabling theft deterrence features
● Energy saver feature to meet requirements for reduced power consumption
NOTE: For safety and regulatory information, refer to the Product Notices provided in your documentation
kit. To access the latest user guides or manuals for your product, go to http://www.hp.com/support and
follow the instructions to find your product. Then select Manuals.

HP M24FD Specifications

General

Color gamut	99 %
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	Edge LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	117 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI, USB Type-C
HDMI version	1.4
USB Type-A downstream ports quantity	2
Package depth	121 mm
Package width	610 mm
Package height	399 mm
Package weight	5100 g
Tilt angle range	-5 - 25 °
Product color	Silver
Market positioning	Home
Depth	34 mm
Height	315.6 mm

Weight and Dimensions

Depth (with stand)	39.68 mm
Width (with stand)	53.58 mm
Height (with stand)	17.72 mm
Weight (with stand)	2600 g
Depth (without stand)	3.4 mm
Width (without stand)	535.8 mm
Height (without stand)	31.56 mm
