HP M24fw User Manual

5
Rear components
To identify the components on the rear of the monitor, use this illustration and table.
Table 2: Rear components and their descriptions
Component
Function
1 Security cable slot
Connects an optional security cable.
2 Power connector
Connects an AC adapter.
3 Power light
On: The monitor is on.
Off: Depending on your monitor model,
the monitor is off or in Sleep Mode.
4 VGA connector
Connects the VGA cable to a source device.
5 HDMI port
Connect the HDMI cable to a source device such
as a computer or game console.

HP M24fw Specifications

General

Color gamut	99 %
Screen shape	Flat
Pixel density	93 ppi
Backlight type	Edge LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 720 (HD 720), 720 x 400, 1280 x 1024 (SXGA), 1280 x 800, 800 x 600 (SVGA), 1440 x 900, 1024 x 768 (XGA), 1600 x 900, 640 x 480 (VGA), 1680 x 1050 (WSXGA+)
HDMI version	1.4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	20 W
Power consumption (standby)	0.5 W
Power consumption (typical)	14.3 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	121 mm
Package width	610 mm
Package height	399 mm
Package weight	4700 g
Tilt angle range	-5 - 25 °
Product color	Silver
Market positioning	Business
HP segment	Home

Weight and Dimensions

Depth (with stand)	177.2 mm
Width (with stand)	535.8 mm
Height (with stand)	396.8 mm
Weight (with stand)	2500 g
Depth (without stand)	34 mm
Height (without stand)	315.6 mm
