Replacing a MIM
W
ARNING!
Before replacing a MIM when the router is powered on, you must execute the remove hmimslot
slotnumbe
r
command first.
To replace a MIM:
1. Completely loosen the captive screws of the HMIM adapter.
2. Gently pull the MIM and the HMIM adapter out of the slot along the slide rails.
Figure 51 Removing a MIM and the HMIM adapter
3. Completely loosen the captive screws of the MIM, loosen and take off the screws securing the MIM
to the HMIM adapter, and pull the MIM out of the HMIM adapter along the slide rails.
Keep the removed MIM for future use.
4. Install a new MIM. For the installation procedure, see "Installing the router."
If you do not install a new MIM in the slot, install a filler panel and tighten the screws.
Figure 52 Removing a MIM
