Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) Display assembly
NOTE: Display spare parts are available only as subcomponents. For spare part information, see Display assembly
subcomponents on page 20.
(2) Top cover with keyboard (backlit)
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 65.
For use in ceramic white models:
● Per key keyboard, models with Thunderbolt N14415-xx1
● 4-zone keyboard N19327-xx1
● 4-zone keyboard, models with Thunderbolt N19328-xx1
For use in shadow black models:
● 1-zone keyboard N14406-xx1
● 4-zone keyboard N14407-xx1
● 1-zone keyboard with numeric keypad N14408-xx1
● 4-zone keyboard with numeric keypad N14409-xx1
● 1-zone keyboard with numeric keypad, models with Thunderbolt N14410-xx1
● 4-zone keyboard with numeric keypad, models with Thunderbolt N14411-xx1
● 1-zone keyboard, models with Thunderbolt N14412-xx1
● 4-zone keyboard, models with Thunderbolt N14413-xx1
● Per key keyboard, models with Thunderbolt N14414-xx1
(3) Touchpad
NOTE: The touchpad cable is available as spare part number N14078-001.
Ceramic white N14076-001
Shadow black N14077-001
(4) Speakers N14088-001
(5) System board
NOTE: The system board repair kit is available as spare part number N19354-888.
Intel Core i9-12900H processor and RTX 3070 Ti graphics, G-Sync N13797-601
Intel Core i9-12900H processor and RTX 3060 graphics N13800-601
Intel Core i7-12700H processor and RTX 3070 Ti graphics N13795-601
Intel Core i7-12700H processor and RTX 3070 Ti graphics, G-Sync N13796-601
Intel Core i7-12700H processor and RTX 3060 graphics N13799-601
Intel Core i7-12700H processor and RTX 3050 graphics N13802-601
Intel Core i7-12700H processor and RTX 3050 Ti graphics N13804-601
Intel Core i5-12500H processor and RTX 3060 graphics N13798-601
18 Chapter 3Illustrated parts catalog
