Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(2) Top cover with keyboard
For a detailed list of country codes, see Top cover with keyboard on page 57.
NOTE: The RGB per-key keyboard cable is available as spare part number M57113-001.
The RGB per-key backlight cable is available as spare part number M57114-001.
For use in models with 4-zone RGB lighting M57142-xx1
For use in models with per-key RGB lighting M57141-xx1
(3) Touchpad (does not include bracket)
NOTE: The touchpad cable is available using spare part number M57110-001.
M62229-001
(4) Speaker, right M57131-001
(5) Speaker, left M57130-001
(6) System board (includes processor; for use in models with discrete graphics memory)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
Intel Core i9-11900H processor and NVIDIA GeForce RTX 3080 graphics (16 GB) M73505-xx1
Intel Core i9-11900H processor and NVIDIA GeForce RTX 3080 graphics (8 GB) M57135-xx1
Intel Core i9-11900H processor and NVIDIA GeForce RTX 3070 graphics M57137-xx1
Intel Core i7-11800H processor and NVIDIA GeForce RTX 3080 graphics (16 GB) M73504-xx1
Intel Core i7-11800H processor and NVIDIA GeForce RTX 3070 graphics M57136-xx1
Intel Core i7-11800H processor and NVIDIA GeForce RTX 3060 graphics M57133-xx1
Intel Core i5-11400H processor and NVIDIA GeForce RTX 3060 graphics M57132-xx1
(7) Battery
6 cell, 83 Whr M41711-005
4 cell, 70 Whr M39179-005
(8) IR sensor board
NOTE: The IR sensor board cable is available as spare part number M57109-001.
M57124-001
(9) Card reader board
NOTE: The card reader board cable is available as spare part number M57108-001.
M57123-001
(10) Memory modules (DDR4-3200)
16 GB L67710-001
8 GB L46598-001
(11) Bottom cover M57106-001
(12) USB board
NOTE: The USB board cable is available using spare part number M57107-001.
M57122-001
16 Chapter 3 Illustrated parts catalog
