1 Product description
This table provides detailed product information.
Table 1-1 Product components and their descriptions
Category Description
Product Name OMEN 17 Laptop PC
Model numbers: 17-ck0xxx
CTO model: 17t-ck000
Processors Intel® processors
Intel Core® i9-11900H (2.5 GHz, turbo up to 5.2 GHz), 3200 MHz/24 MB L3 cache, 8 core, TDP 45W
Intel Core i7-11800H (2.4 GHz, turbo up to 4.6 GHz), 3200 MHz/24 MB L3 cache, 8 core, TDP 45W
Intel Core i5-11400H (2.7 GHz, turbo up to 4.5 GHz), 3200 MHz/12 MB L3 cache, 6 core, TDP 45W
Chipset Intel HM570
Graphics Internal graphics
Intel UHD Graphics
Hybrid graphics
NVIDIA® GeForce® RTX 3080 graphics with up to 16 GB of dedicated GDDR6 video memory
NVIDIA GeForce RTX 3080 graphics with up to 8 GB of dedicated GDDR6 video memory
NVIDIA GeForce RTX 3070 graphics with up to 8 GB of dedicated GDDR6 video memory
NVIDIA GeForce RTX 3060 graphics with up to 6 GB of dedicated GDDR6 video memory
Supports HD Decode, DX12, and HDMI
Supports Optimus®
Supports GPS (GPU Performance Scaling)
Mixed reality (MR) compatible (60 Hz frame rate)
Display 17.3 in (43.9 cm), antiglare, ultrawide viewing angle (UWVA), eDP 1.4 + PSR, narrow bezel, 300 nits
Full high-denition (FHD) (1920 × 1080), at (3.2 mm), sRGB 100, low blue light, 144 Hz
FHD, at (3.2 mm), 72% NTSC, 60 Hz
Quad high-denition (QHD) (2560 × 1440), slim (2.6 mm), sRGB 100, low blue light, 165 Hz
Memory Customer accessible or upgradeable
Two SODIMM slots, dual-channel support
DDR4-3200 (i9/i7 processors) or DDR-2933 (i5 processor)
Supports the following congurations:
32 GB (16 × 2)
1
