Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(13) Power connector (DC-in) cable M57115-001
(14) Rear n not available as a
spare part
(15) Solid-state drive
1 TB, PCIe-4 × 4 M16560-001
1 TB, PCIe-3 × 4 L85348-001
512 GB, PCIe-4 × 4 M17436-001
512 GB, PCIe-3 × 4 L85360-001
512 GB + 32 GB Optane memory L85366-001
(16) RJ-45 door M57116-001
(17) Fans M57139-001
(18) Heat sink
NOTE: The thermal grease and pad kit is available as spare part number M57118-001.
M57140-001
WLAN module (not illustrated)
NOTE: WLAN module protective shielding is available as spare part number M14330-001.
Intel Wi-Fi 6 AX201-W + Bluetooth 5 (non-vPro) L92724-006
Intel Wi-Fi 6 AX210 + Bluetooth 5.2 (non-vPro) M27269-006
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Display assembly subcomponents 17
