Recipient Control Flags: 0 Rxsz: 800
Example for Direct Connect
# fcmsutil /dev/fcd0 get remote all
Target N_Port_id is = 0x0000ef
Target Loop_id is = 0
Target state = DSM_UNOPENED
Symbolic Name =
Port Type = NL_PORT
FCP-2 Support = NO
Target Port World Wide Name = 0x20020002ac00003e
Target Node World Wide Name = 0x2ff70002ac00003e
Common Service parameters (all values shown in hex):
^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Common Features : 8800 RO_Bitmap: fe
Total Conseq: ff
Class 3 Service parameters (all values shown in hex):
^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
Open Sequences/Exchg: 1 Conseq: ff
Recipient Control Flags: 0 Rxsz: 800
11. To find the storage volume serial number for the corresponding disk id on the HP-UX host, use
the cstm command. The HP Online diagnostic tool must be installed to access the cstm
command. For example:
# cstm
# selclass type disk
# info
# infolog
. . .
Hardware path: 0/2/0/0.8.0.0.0.0.4
The selected device is not supported by this tool.
Inaccurate information could be displayed by the tool.
Product Id: VV Vendor: 3PARdata
Device Type: SCSI Disk Firmware Rev: 0000
Device Qualifier: 3PARdataVV Logical Unit: 4
Serial Number: 003B003E
Capacity (M Byte): 4096.00
Block Size: 512
Max Block Address: 8388607
. . .
Check the ioscan -fun disk for the given hardware path and use the HP 3PAR Storage System
CLI command showvlun -lvw or showvv -d to get the volume name. The data which
matches is in bold font:
# showvlun -lvw -host <hostname>
. . .
Active VLUNs
Lun VVname -----VV_WWN----- Host ----Host_WWN---- Port Type
4 hpuxN.0 50002AC0003B003E hp 50060B0000101A4C 1:0:3 host
4 hpuxN.0 50002AC0003B003E hp 50060B00000670A8 2:1:1 host
. . .
12. If an HP 3PAR Storage System node is rebooted or an HP 3PAR Storage System Cluster is
rebooted and the connection type is Direct, performing an ioscan or I/O on any storage
volume connected to the Agilent A6795A, A5158A HBA is required in order to see the host
WWN with the showhost command. This is because the HPUX host driver log's into the
target port only on doing one of the above operations.
36 Allocating Storage for Access by the HP-UX Host
