3
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
54.5 cm (21.5 in) diagonal viewable screen area with 1920 × 1080 resolution
Vertical Alignment (VA) panel
Nonglare panel with an LED backlight
Wide viewing angle to allow viewing from a sitting or standing position, or moving from side to side
Tilt capabilities
Removable stand for Flexible monitor head mounting solutions
HP Quick Release 2 device to quickly attach the monitor head to the stand with a simple click, and
then remove it with the convenient sliding tab release
High-Definition Multimedia Interface™ (HDMI) video input (cable included)
VGA video input (cable included in select regions)
A 4-way on-screen display (OSD) controller that you can reconfigure to quickly allow selection of
three most commonly used operations
Plug and Play capability if supported by your operating system
VESA® mounting bracket for attaching the monitor head to a wall-mount device or swing arm
Security cable slot on the rear of the monitor for an optional security cable
Cable management feature for placement of cables and cords
On-screen adjustments in several languages for easy setup and screen optimization
Energy saver feature to meet requirements for reduced power consumption
NOTE: For safety and regulatory information, refer to the Product Notices provided in your
documentation kit. To access the latest user guides or manuals for your product, go to
http://www.hp.com/support and follow the instructions to find your product. Then select Manuals.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP P22v G5 and is the answer not in the manual?

HP P22v G5 Specifications

General IconGeneral
Color depth8 bit
Color gamut72 %
Pixel pitch0.25 x 0.24 mm
Screen shapeFlat
Pixel density103 ppi
Display diagonal21.45 \
Surface hardness3H
Native aspect ratio16:9
Vertical scan range48 - 75 Hz
Maximum refresh rate75 Hz
Horizontal scan range54 - 88.1 kHz
Contrast ratio (dynamic)8000000:1
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Display diagonal (metric)54.5 cm
Display brightness (typical)200 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDCPYes
HDMI version1.4
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)21 W
Power consumption (standby)0.5 W
Power consumption (typical)11 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Tilt angle range-5 - 23 °
Panel mounting interface100 x 100 mm
Feet colorBlack
Market positioningBusiness
Package weight4300 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)180.5 mm
Width (with stand)504.2 mm
Height (with stand)386.9 mm
Weight (with stand)2800 g
Depth (without stand)50.8 mm
Height (without stand)303 mm
