HP Pavilion dv1000 Hardware And Software Guide

7–10 Hardware and Software Guide
Hardware Upgrades and Replacements
Stopping and Removing a PC Card
Ä
CAUTION: To prevent loss of work or an unresponsive system, stop the
PC Card before removing it.
✎
Stopping a PC Card, even if it is not in use, conserves power.
To stop or remove a PC Card:
1. Close all applications and complete all activities that are
supported by the PC Card. Then
❏ To stop the PC Card, select the Safely Remove Hardware
icon on the taskbar, and then select the PC Card. (To
display the Safely Remove Hardware icon, right-click
the taskbar, select Properties, clear the Hide inactive
icons check box, and then select OK.)
❏ To remove the PC Card, stop the PC Card as described
above, and then proceed to step 2.
2. Press the PC Card eject button 1. (You may need to press the
button once to extend the button, and then press the button
again to release the PC Card.)
3. Gently slide out the PC Card 2.

HP Pavilion dv1000 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Operating System	Windows XP Home or Professional
RAM	256 MB - 2 GB DDR
Graphics	Intel GMA 900
Weight	2.4 kg
Battery Life	Up to 3.5 hours
Optical Drive	DVD-ROM
Wireless	802.11b/g
Chipset	Intel 915GM
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone
Display	14.1-inch WXGA
