Specifications
Hardware and Software Guide A–3
Expansion Port Input/Output Signals
The expansion port signal information in this section may be
helpful if you plan to use an optional expansion product that
connects to the Expansion Port 2 on your notebook (The term
Expansion Port 2 describes the type of expansion port.).
The Expansion Port 2 is illustrated in the “Left-Side
Components” section of Chapter 1, “Component ID.”
The following table identifies the input and output signals
supported by the Expansion Port 2 on your notebook.
Feature Support
USB 2.0 Ye s
10/100 Ethernet Ye s
Gigabit Ethernet No
IEEE 1394 (4-pin port) Ye s
Consumer IR (for optional remote control only) Ye s
Power inputs 90-135W maximum
Composite TV* Ye s
S-Video TV Ye s
Component TV No
S/PDIF audio* Ye s
DVI No
Headphone/speaker audio-out Ye s
Microphone audio-in Ye s
*Requires the use of an optional expansion product.
