Removal and Replacement Procedures
Maintenance and Service Guide 5–49
7. Swing the rear edge of the top cover up and forward 1 until it
rests at an angle.
8. Lift the top cover up and remove it 2.
Removing the Top Cover, HP Pavilion dv4000 Models
Reverse the above procedure to install the top cover.
