7.
If it is necessary to replace the display hinges:
a. Remove the eight Phillips PM2.0×3.0 screws (1) that secure the display hinges to the
display panel.
b. Remove the display hinges (2). The display hinges include the display hinges and brackets
and are available using spare part number 665599-001.
8. If it is necessary to replace the display panel cable:
a. Disconnect the display logo light cable (1) from the display panel cable.
b. Release the display panel cable (2) from the clips (3) built into the display enclosure.
102 Chapter 4 Removal and replacement procedures
