Hard drive
NOTE: The hard drive spare part kit does not include the bracket, connector cable, Mylar shield,
or screws. The bracket, connector cable, Mylar shield, and screws are included in the Hard Drive
Hardware Kit, spare part number 665597-001.
NOTE: The computer can be equipped with up to two hard drives. The primary hard drive is installed
in the right hard drive bay. The secondary hard drive is installed in the left hard drive bay.
Description Spare part number
1-TB, 5400-rpm, 12.7-mm 638974-001
750-GB, 7200-rpm, 9.5-mm 633252-001
750-GB, 5400-rpm, 9.5-mm 634250-001
640-GB, 5400-rpm, 9.5-mm 603785-001
500-GB, 7200-rpm, 9.5-mm 608218-001
500-GB, 5400-rpm, 9.5-mm 634932-001
320-GB, 7200-rpm, 9.5-mm 634862-001
320-GB, 5400-rpm, 9.5-mm 622643-001
160-GB solid-state drive (does not include bracket, connector cable, Mylar shield, or screws) 665985-001
Before removing a hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 47).
5. Remove the service cover (see
Optical drive on page 48).
Remove the hard drive:
NOTE: Steps 1 through 3 apply to the primary hard drive. See steps 4 through 7 for secondary
hard drive removal information.
1.
Disconnect the hard drive cable (1) from the system board.
2. Remove the four Philllips PM2.5×5.0 screws (2) that secure the hard drive to the computer.
Component replacement procedures
51
