6.
Remove the optical drive (2) from the computer.
7. If it is necessary to replace the optical drive bracket, position the optical drive with the rear panel
toward you.
8. Remove the two Phillips PM2.0×4.0 screws (1) that secure the bracket to the optical drive.
9. Remove the optical drive bracket (2). The optical drive bracket is included in the optical drive
spare part kit.
Reverse this procedure to reassemble and install the optical drive.
50 Chapter 4 Removal and replacement procedures
