3.
Remove the subwoofer (4) and cables.
Reverse this procedure to install the subwoofer and cables.
Display assembly
NOTE: The display assembly is spared at the subcomponent level only. For more display assembly
spare part information, see the individual removal subsections.
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 47), and then remove the following components:
●
Optical drive (see
Optical drive on page 48)
●
Hard drive (see
Hard drive on page 51)
●
WLAN module (see
WLAN module on page 56)
●
Keyboard (see
Keyboard on page 59)
●
Top cover (see
Top cover on page 62)
●
System board (see
System board on page 81)
●
Rear speakers (see
Rear speakers on page 94)
Component replacement procedures
97
