Remove the display assembly:
1. Release the wireless antenna cables from the clips (1) and the opening in the base enclosure.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other
computer components.
2. Remove the six Phillips PM2.5×5.0 screws (2) and (3) that secure the display assembly to
the computer.
NOTE: The middle screw (3) on the left hinge secures the display panel cable ground loop to
the hinge.
3. Remove the display assembly (4).
98 Chapter 4 Removal and replacement procedures
