4.
If it is necessary to replace the display bezel or any of the display assembly subcomponents:
a. Remove the Mylar screw covers (1) and the two Phillips PM2.5×5.0 screws (2) that secure
the display bezel to the display assembly.
b.
Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom
edge (3) of the display bezel until the bezel disengages from the display enclosure.
c. Remove the display bezel (4). The display bezel is available using spare part number
665592-001.
Component replacement procedures
99
