Display assembly subcomponents
Item Component Spare part number
(1) Display bezel 665592-001
(2) Display Hinge Kit (includes left and right display hinges and brackets) 665599-001
(3) Display panel:
17.3-in, FHD, LED, AntiGlare display panel for use only with computer models equipped
with an Intel processor
666397-001
17.3-in, HD+, LED, BrightView display panel for use with all computer models 666396-001
(4) Display Cable Kit (includes display panel cable and webcamera/
microphone module cable)
665594-001
(5) Webcamera/microphone module 665365-001
(6) Antenna Kit (includes left and right wireless antenna cables and transceivers) 665591-001
(7) Display enclosure:
In dark umber finish 665976-001
In steel gray finish 665977-001
Display Rubber Kit (not illustrated, include Mylar screw covers) 665607-001
Display Screw Kit (not illustrated) 665609-001
30 Chapter 3 Illustrated parts catalog
