Phillips PM2.5×6.0 captive screw
Color Quantity Length Thread Head diameter
Black 10 6.0 mm 2.5 mm 5.0 mm
Where used:
(1) 4 captive screws that secure the primary hard drive cover to the computer (screws are secured by
a C-clip)
(2) 3 captive screws that secure the secondary hard drive cover to the computer (screws are secured
by a C-clip)
Phillips PM2.5×6.0 captive screw 117
