5.
If it is necessary to replace the display panel:
a. Remove the ten Phillips PM2.5×5.0 screws that secure the display panel to the
display enclosure.
b. Lift the top edge of the display panel, and then swing it up and forward until it rests upside
down in front of the display enclosure.
100 Chapter 4 Removal and replacement procedures
