7.
Release the ZIF connectors to which the following cables are attached, and then disconnect
the cables from the system board:
(1) Power button board cable
(2) TouchPad button board cable
(3) Fingerprint reader board cable
(4) USB board cable
8. Remove the two Phillips PM2.5×5.0 screws that secure the top cover to the computer.
NOTE: As you prepare to release the top cover, make sure the USB board (2) cable feeds freely
through the opening (3) in the top cover.
9. Lift the rear edge of the top cover (1) until the left and right sides disengage from the
base enclosure.
64 Chapter 4 Removal and replacement procedures
