3.
Release the Bluetooth module (3) from the clip built into the base enclosure.
4. Remove the Bluetooth module and cable.
5. If it is necessary to replace the Bluetooth module cable, disconnect the cable from the
Bluetooth module.
Reverse this procedure to install the Bluetooth module and cable.
Component replacement procedures
75
