Rear Components
Figure 1-3 Rear Components
Table 1-2 Rear Components
Component Component
1 Power Button 7 Headphone jack
2 LED Indicator (HDD activity) 8 Line out
3 LED Indicator (Card reader activity) 9 Ethernet
4 6-in-1 Media Card Reader 10 4 USB 2.0 ports
5 2 USB 2.0 11 DC Power-In Connector
6 MIC jack 12 LED Indicator (power)
Rear Components 3
