Side I/O Cover
Description Spare part number
Side I/O cover 669987-001
The side I/O cover is located on the right side of the computer (viewed from behind). Press the tabs to
remove it.
Figure 7-24 Side I/O cover location
To remove the side I/O cover:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 34).
2. Remove the rear cover (see
Rear Cover on page 35).
56 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
