Page #155 background imageLoading...
Page #155 background image
Cursor will not move using the arrow keys on the keypad.
Cause Solution
The Num Lock key is turned on. Press the Num Lock key. The Num Lock light must be off if
you want to use the arrow keys on the keypad. You can also
disable or enable the Num Lock key in Computer Setup at
Advanced > Device Options.
There is no sound or sound volume is too low.
Cause Solution
System volume may be set low or muted. 1. Check the Computer Setup settings to make sure the
internal system speaker is not muted (this setting does
not affect the external speakers).
2. Make sure the external speakers are properly
connected and powered on and that the speakers'
volume control is set correctly.
3. Use the system volume control available in the
operating system to make sure the speakers are not
muted or to increase the volume.
Cannot remove computer cover or access panel.
Cause Solution
Smart Cover Lock, featured on some computers, is locked. Unlock the Smart Cover Lock using Computer Setup.
In case of forgotten password, power loss, or computer
malfunction, you must manually disable the Smart Cover
lock . A key to unlock the Smart Cover Lock is not available
from HP. Keys are typically available from a hardware store.
Poor performance.
Cause Solution
Processor is too hot. 1. Make sure airflow to the computer is not blocked. Leave
a 10.2-cm (4-inch) clearance on all vented sides of the
computer and above the monitor to permit the required
airflow.
2. Make sure fans are connected and working properly
(some fans only operate when needed).
3. Make sure the processor heat sink is installed properly.
Hard drive is full. Transfer data from the hard drive to create more space on
the hard drive.
Low on memory. Add more memory.
Hard drive fragmented. Defragment hard drive.
Program previously accessed did not release reserved
memory back to the system.
Restart the computer.
Solving General Problems 145

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pro 3330 Microtower and is the answer not in the manual?

HP Pro 3330 Microtower Specifications

General IconGeneral
Product typePC
Motherboard chipsetIntel® H61
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3220
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor socketLGA 1155 (Socket H2)
Processor threads4
Processor codenameIvy Bridge
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)55 W
Number of processors installed1
CPU multiplier (bus/core ratio)33
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1333 MHz
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Number of SSDs installed0
Cooling type-
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Processor ARK ID65693
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal solution specificationPCG 2011C
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Power supply300 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz
Weight and Dimensions IconWeight and Dimensions
Depth421.1 mm
Width173.2 mm
Height382.3 mm
Weight10000 g
