To clean the computer case, follow the procedures described below:
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
For stronger stains, use a mild dishwashing liquid diluted with water. Rinse well by wiping it with
a cloth or swab dampened with clear water.
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is needed as the alcohol will
evaporate quickly and not leave a residue.
After cleaning, always wipe the unit with a clean, lint-free cloth.
Occasionally clean the air vents on the computer. Lint and other foreign matter can block the
vents and limit the airflow.
Cleaning the Keyboard
Follow all safety precautions in General Cleaning Safety Precautions on page 44 before cleaning the
keyboard.
To clean the tops of the keys or the keyboard body, follow the procedures described in
Cleaning the
Computer Case on page 44.
When cleaning debris from under the keys, review all rules in
General Cleaning Safety Precautions
on page 44 before following these procedures:
CAUTION: Use safety glasses equipped with side shields before attempting to clean debris from
under the keys.
Visible debris underneath or between the keys may be removed by vacuuming or shaking.
Canned, pressurized air may be used to clean debris from under the keys. Caution should be
used as too much air pressure can dislodge lubricants applied under the wide keys.
If you remove a key, use a specially designed key puller to prevent damage to the keys. This
tool is available through many electronic supply outlets.
CAUTION: Never remove a wide leveled key (like the space bar) from the keyboard. If these
keys are improperly removed or installed, the keyboard may not function properly.
Cleaning under a key may be done with a swab moistened with isopropyl alcohol and squeezed
out. Be careful not to wipe away lubricants necessary for proper key functions. Use tweezers to
remove any fibers or dirt in confined areas. Allow the parts to air dry before reassembly.
Cleaning the Monitor
Wipe the monitor screen with a clean cloth moistened with water or with a towelette designed for
cleaning monitors. Do not use sprays or aerosols directly on the screen; the liquid may seep into
the housing and damage a component. Never use solvents or flammable liquids on the monitor.
To clean the monitor body follow the procedures in
Cleaning the Computer Case on page 44.
Routine Care 45

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pro 3330 Microtower and is the answer not in the manual?

HP Pro 3330 Microtower Specifications

General IconGeneral
Product typePC
Motherboard chipsetIntel® H61
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3220
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor socketLGA 1155 (Socket H2)
Processor threads4
Processor codenameIvy Bridge
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)55 W
Number of processors installed1
CPU multiplier (bus/core ratio)33
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1333 MHz
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Number of SSDs installed0
Cooling type-
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Processor ARK ID65693
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal solution specificationPCG 2011C
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Power supply300 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz
Weight and Dimensions IconWeight and Dimensions
Depth421.1 mm
Width173.2 mm
Height382.3 mm
Weight10000 g
