System Fan
Description Spare part number
Fan 657103-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 48).
2. Remove the access panel (
Access Panel on page 49).
3. Lay the computer on its side with the rear facing toward you.
4. Remove the four Phillips screws that secure the fan to the chassis.
Figure 7-41 Removing the fan screws
System Fan 87
