Solving Keyboard and Mouse Problems
If you encounter keyboard or mouse problems, see the documentation that came with the equipment
and to the common causes and solutions listed in the following table.
Table A-8 Solving Keyboard Problems
A wireless keyboard/mouse is not working correctly. Symptoms include lagging mouse movement, jumpy mouse/
keyboard, or no function of mouse/keyboard and external drive.
Cause Solution
If your computer is equipped with USB 3.0 ports, connected
USB 3.0 devices can interfere with the wireless keyboard
USB receiver.
Connect the wireless keyboard USB receiver to a USB 2.0
port that is separated from ports with USB 3.0 devices. If you
still experience interference, you may have to place the
connectors farther apart using an external USB hub.
Keyboard commands and typing are not recognized by the computer.
Cause Solution
Keyboard connector is not properly connected. Shut down the computer, reconnect the keyboard to the back
of the computer, and then restart the computer.
Program in use has stopped responding to commands. Shut down your computer using the mouse and then restart
the computer.
Keyboard needs repairs. See the Worldwide Limited Warranty for terms and
conditions.
Computer is in Sleep state. Press the power button to resume from Sleep state.
CAUTION: When attempting to resume from Sleep date,
do not hold down the power button for more than four
seconds. Otherwise, the computer will shut down and you
will lose any unsaved data.
Cursor will not move using the arrow keys on the keypad.
Cause Solution
The Num Lock key is on. Press the Num Lock key. The Num Lock light should be off if
you want to use the arrow keys on the keypad. You can
disable or enable the Num Lock key in Computer Setup at
Advanced > Device Options.
164 Appendix A Troubleshooting Without Diagnostics

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pro 3330 Microtower and is the answer not in the manual?

HP Pro 3330 Microtower Specifications

General IconGeneral
Product typePC
Motherboard chipsetIntel® H61
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3220
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor socketLGA 1155 (Socket H2)
Processor threads4
Processor codenameIvy Bridge
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)55 W
Number of processors installed1
CPU multiplier (bus/core ratio)33
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1333 MHz
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Number of SSDs installed0
Cooling type-
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Processor ARK ID65693
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal solution specificationPCG 2011C
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Power supply300 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz
Weight and Dimensions IconWeight and Dimensions
Depth421.1 mm
Width173.2 mm
Height382.3 mm
Weight10000 g
