Page #21 background imageLoading...
Page #21 background image
Computer Setup—Storage
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 3-3 Computer Setup—Storage
Option Description
Device Configuration Lists all installed BIOS-controlled storage devices.
When a device is selected, detailed information and options are displayed. The following options
may be presented:
Hard Disk: Size, model, firmware version, serial number, connector color.
Translation mode (ATA disks only)
Lets you select the translation mode to be used for the device. This enables the BIOS to
access disks partitioned and formatted on other systems and may be necessary for users of
older versions of UNIX (e.g., SCO UNIX version 3.2). Options are Automatic, Bit-Shift,
LBA Assisted, User, and Off.
Available only when the drive translation mode is set to User, allows you to specify the
parameters (logical cylinders, heads, and sectors per track) used by the BIOS to translate
disk I/O requests (from the operating system or an application) into terms the hard drive can
accept. Logical cylinders may not exceed 1024. The number of heads may not exceed 256.
The number of sectors per track may not exceed 63.
CAUTION: Ordinarily, the translation mode selected automatically by the BIOS should not
be changed. If the selected translation mode is not compatible with the translation mode that
was active when the disk was partitioned and formatted, the data on the disk will be
inaccessible.
CD-ROM: Model, firmware version, serial number, connector color (not included for USB CD-
ROM).
SSD Life Used
NOTE: Displays for solid-state drives.
SMART (ATA disks only)
Diskette: Model and firmware version.
NOTE: Displays for USB diskette drives.
Default Values (ATA disks only)
See Translation Mode above for details.
SATA Defaults
Computer Setup (F10) Utilities 11

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Pro 3330 Microtower and is the answer not in the manual?

HP Pro 3330 Microtower Specifications

General IconGeneral
Product typePC
Motherboard chipsetIntel® H61
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3220
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor socketLGA 1155 (Socket H2)
Processor threads4
Processor codenameIvy Bridge
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorYes
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)55 W
Number of processors installed1
CPU multiplier (bus/core ratio)33
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2x DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed1333 MHz
Maximum internal memory8 GB
Memory layout (slots x size)1 x 4 GB
HDD size3.5 \
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Number of SSDs installed0
Cooling type-
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Recovery operating systemWindows 8 Pro
Operating system installedWindows 7 Professional
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity6
Chassis typeMicro Tower
Product colorBlack
Country of originChina
Processor ARK ID65693
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal solution specificationPCG 2011C
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Power supply300 W
Power supply input voltage100 - 240 V
Power supply input frequency50 - 60 Hz
Weight and Dimensions IconWeight and Dimensions
Depth421.1 mm
Width173.2 mm
Height382.3 mm
Weight10000 g
