WLAN module
Description Spare part number
Intel Dual Band Wireless-N 7260AN 802.11a/b/g/n 2×2 WiFi + BT 4.0 Combo Adapter for
use only on HP Pro x2 410 G1 PC computer models
717381-005
For use on all computer models:
Intel Wireless-N 7260BN 802.11b/g/n 2×2 WiFi + BT 4.0 Combo Adapter 717384-005
Ralink RT3290LE 802.11b/g/n 1×1 WiFi and Bluetooth 4.0 Combo Adapter 690020-005
Before removing the rear-facing webcamera, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the display enclosure (see
Display enclosure on page 38).
5. Disconnect the tablet battery cable from the system board (see
Sensor board on page 39).
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless
module authorized for use in the computer by the governmental agency that regulates wireless devices
in your country or region. If you replace the module and then receive a warning message, remove the
module to restore device functionality, and then contact technical support.
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal
labeled “1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal
labeled “2”.
2. Remove the Phillips PM1.85×3.00 screw (2) that secures the WLAN module to the system board.
(The WLAN module tilts up.)
Tablet component replacement procedures
45
