3. Remove the docking board (2).
Reverse this procedure to install the docking board.
Hinge assembly
NOTE: The hinge assembly spare part kit includes two cables and two rubber feet.
Description Spare part number
For use only on HP Pro x2 410 G1 PC keyboard bases 759019-001
For use only on HP Pavilion 11 x2 PC keyboard bases:
In flyer red finish 740204-001
In pearl white finish 740205-001
In sparkling white finish 740203-001
Before removing the hinge assembly, follow these steps:
1. Turn off the tablet and keyboard base. If you are unsure whether the tablet and keyboard base are
off or in Hibernation, turn the tablet on, and then shut it down through the operating system.
2. Disconnect the power from the tablet and keyboard base by unplugging the power cord from the
tablet and keyboard base.
82 Chapter 5 Removal and replacement procedures
